Chung Metal is one of the major suppliers of Super Duplex Steel S32760 Forgings in Da Nang, Vietnam. These forgings are formulated for ultimate resistance to pitting, erosion, and stress-corrosion cracking. Being a blend of high strength and excellent corrosion resistance, S32760 finds application in demanding industrial processes. Chung Metal maintains consistency through sophisticated forging, heat treatment, and machining processes. These products conform to international quality standards and provide reliability in corrosive conditions, and thus Chung Metal is a reliable partner for super duplex steel components.
S32760 is composed of 25% chromium, 7% nickel, 3.6% molybdenum, 0.3% nitrogen, and tungsten additions. It offers tensile strength of 850 MPa, yield strength of 550 MPa, and elongation of approximately 25%. The duplex structure provides high toughness and resistance to chlorides even at high pressures.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4501 | S32760 |
Yes, Super Duplex Steel S32760 forgings are highly suitable for offshore and marine applications due to their excellent corrosion resistance, high strength, and resistance to pitting, crevice corrosion, and chloride stress cracking.
Welding processes compatible with Super Duplex Steel S32760 forgings include Tungsten Inert Gas (TIG), Metal Inert Gas (MIG), and Shielded Metal Arc Welding (SMAW), using matching filler materials to maintain corrosion resistance.
Super Duplex Steel S32760 forgings are governed by ASTM A182, ASTM A240, ASME SA-182, and EN 10088-3 standards, ensuring quality, corrosion resistance, and mechanical properties for demanding industrial applications.
S32760 forgings are suitable for chemical tankers, subsea piping, offshore structures, and pressure vessels. They are resistant to localized corrosion, erosion, and stress-cracking. Chung Metal’s S32760 forgings offer dependability and lifespan in marine, oil & gas, and desalination sectors where harsh environments dominate.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chung Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Da Nang, Vietnam
