Chung Metal provides Inconel 600 Bars and Rods, a nickel-chromium alloy possessing high corrosion and heat resistance with good mechanical properties. Alloy 600 finds use where there is both temperature and oxidizing or mild reducing conditions present, and where maximum resistance to scaling, creep, and oxidation is required. Our bars/rods of 600 are produced with uniform chemistry, good manufacturability, and surface finish to fulfill industrial and chemical application requirements.
Common composition: ~72% nickel, ~14‑17% chromium, balance predominantly iron, trace amounts of carbon, manganese, silicon. Tensile strength ~550‑700 MPa depending on annealed or cold‑worked condition; yield strength less; elongation reasonable (~30‑50%) depending on condition. High resistance to oxidation and scaling at high temperatures, up to around 1000‑1100 °C in some atmospheres. Creep strength moderate; hardness moderate in annealed condition. Good weldability and ductility.
Specification : ASTM B 166 / ASME SB 166
Dimensions : ASTM, ASME and API
Size : 5 mm To 500 mm Dia in 100 mm TO 6000 mm Length available with NACE MR 01-75.
Length : 100 mm To 3000 mm Long & Above
Finish : Bright, Polish & Black
Grade : Inconel 600 – UNS N06600
Form : Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.
Our Inconel 600 Round Bars conforms to NACE MR0175/ISO 15156
| Grade | Ni | Cr | Fe | C | Mn | S | Si | Cu |
| Inconel 600 | 72.0 min | 14.0 – 17.0 | 6.0 – 10.0 | 0.15 max | 1.0 max | 0.015 max | 0.5 max | 0.5 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Temperature | Coefficient of Expansion | Electrical Resistivity | Thermal Conductivity | Specific Heat | |||||
|---|---|---|---|---|---|---|---|---|---|
| °F | °C | 10-6in/in•°F | mm/m•°C | ohm•circ•mil/ft | mL•m | Btu•in/ft2•h•°F | W/m•°C | Btu/lb•°F | J/kg•°C |
| -250 | -150 | 6 | 10.9 | – | – | 86 | 12.5 | 0.073 | 310 |
| -200 | -100 | 6.3 | 11.7 | – | – | 89 | 13.1 | 0.079 | 352 |
| -100 | -50 | 6.7 | 12.3 | – | – | 93 | 13.6 | 0.09 | 394 |
| 70 | 20 | 5.8 | 10.4 | 620 | 1.03 | 103 | 14.9 | 0.106 | 444 |
| 200 | 100 | 7.4 | 13.3 | 625 | 1.04 | 109 | 15.9 | 0.111 | 465 |
| 400 | 200 | 7.7 | 13.8 | 634 | 1.05 | 121 | 17.3 | 0.116 | 486 |
| 600 | 300 | 7.9 | 14.2 | 644 | 1.07 | 133 | 19 | 0.121 | 502 |
| 800 | 400 | 8.1 | 14.5 | 657 | 1.09 | 145 | 20.5 | 0.126 | 519 |
| 1000 | 500 | 8.4 | 14.9 | 680 | 1.12 | 158 | 22.1 | 0.132 | 536 |
| 1200 | 600 | 8.6 | 15.3 | 680 | 1.13 | 172 | 23.9 | 0.14 | 578 |
| 1400 | 700 | 8.9 | 15.8 | 680 | 1.13 | 186 | 25.7 | 0.145 | 595 |
| 1600 | 800 | 9.1 | 16.1 | 686 | 1.13 | 200 | 27.5 | 0.149 | 611 |
| 1800 | 900 | 9.3 | 16.4 | 698 | 1.15 | – | – | – | 628 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF600 | NA 13 | МНЖМц 28-2.5-1.5 | – | NiCr15Fe |
Yes, Inconel 600 bars/rods offer excellent resistance to high temperatures, maintaining strength and oxidation resistance in applications up to 2000°F (1093°C).
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@chungmetal.com
Yes, Inconel 600 bars/rods exhibit exceptional resistance to oxidation, chlorides, and a wide range of acids, making them ideal for harsh chemical and marine environments.
Applied in furnace components, heat treating equipment, chemical processing, nuclear plants, petrochemical facilities, nuclear engineering, and where high resistance to oxidizing and reducing environments is required (for example sulphur, chlorine). Also utilized in exhaust manifolds, piping for high temperature service, and apparatus which can be subjected to steam or other high temperature conditions. Due to its favorable oxidation, corrosion, and mechanical characteristics, it is widely used where cost vs performance compromise is of concern.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
