Chung Metal produces Inconel 718 Bars and Rods, a precipitation‑hardenable nickel‑chromium superalloy that possesses high tensile strength, superior creep strength, and excellent performance over an extensive range of temperatures. Alloy 718 is extensively utilized in aerospace, gas turbines, nuclear, and structural applications owing to the fact that it can sustain strength and toughness from cryogenic to approximately 700 °C. Our 718 rods/bars are aged, heat treated, and manufactured to high chemical and mechanical specifications for reliable and durable performance in challenging environments.
Composition: approximately 50‑55% nickel, 17‑21% chromium, 2.8‑3.3% molybdenum, 4.75‑5.50% niobium (columbium) + tantalum, with titanium (~0.65‑1.15%), aluminum (~0.2‑0.8%), along with small quantities of iron, cobalt, manganese, silicon, carbon etc. In aged (T6 / peak aged) condition, representative tensile strength ~1250‑1350 MPa, yield strength ~1000‑1200 MPa, elongation ~12‑25%. Good fatigue, creep, rupture strength; retains strength at elevated temperature (~650‑700 °C). Density ~8.19 g/cm³. Good weldability and toughness.
| Specifications | ASTM B116 / ASTM SB116 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 5 mm to 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 100 mm To 3000 mm Long & Above |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | C | Mn | Si | Cu | S | Fe | Mo | Ni | Cr |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.30 max | 0.15 min | – | – | 50 – 55 | 17 – 21 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Density | 8.2 g/cm³ |
Melting point | 1260-1340 ℃ |
Yes, the exceptional corrosion resistance of Inconel 718 makes it highly suitable for marine environments, where it can withstand saltwater and harsh conditions.
Inconel 718 Bars and Rods are primarily used in aerospace, oil and gas, chemical processing, and marine industries for their high strength, corrosion resistance, and performance at elevated temperatures.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@chungmetal.com
Applied in aerospace engine components (e.g., turbine discs, shafts, bolts, fasteners), nuclear reactor parts, high temperature pumps and valves, high load structural parts, and wherever high strength at high temperature is required. Also applied in cryogenic service, gas turbines, rocket propulsion parts, marine turbine components, and oil & gas sector. Its well-balanced mechanical, thermal, and corrosion-resistance characteristics make it one of the most versatile superalloys.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
