Da Nang’s Chung Metal offers Stainless Steel 904L round bars and rods featuring great corrosion resistance coupled with outstanding mechanical stability. These austenitic high alloy rounds are made with strict specifications to provide precision in diameter, smoothness on the surface, and stability in structure. Having been formulated for application where the environment is chemically corrosive, SS 904L rounds find their suitable applications in piping, shafting, and parts necessitating a clean surface and high resilience. Our production ensures stability, low porosity, and high toughness. Shippers who require durable performance over the long term in marine, chemical, and high-humidity conditions select Chung Metal’s 904L rounds for dependability and low maintenance.
SS 904L contains ~25‑28 % chromium, ~20‑25 % nickel, ~4‑5 % molybdenum, ~1‑2 % copper, very little carbon (<0.02 %), possibly nitrogen strengthened. It has tensile strength approximately 500‑700 MPa, yield strength ~200‑300 MPa, elongation ~40‑50 %. Hardness is generally ~150‑230 HB based on finish and treatment. It has excellent impact toughness, and good ductility over wide temperature ranges. Corrosion resistance is exceptional in chloride, sulphuric acid, and seawater exposures, with high resistance to pitting, crevice corrosion, and stress corrosion cracking.
| Standards | ASTM / ASME |
| Designation | B 649, SB 649 |
| Grade | 904L Round Bars and Rods 904L Round Bars and Rods: ASTM B 649, ASME SB 649 |
EN/DIN | 1.4539 X1NiCrMoCu25-20-5 |
|---|---|
AFNOR | Z2CNDU25.20 |
UNS | N08904 |
AISI | 904L / F904L |
BS | 904S13 |
SS | 2562 |
OTHER | ASTM A182 ASTM A262 ASTM A479 ASTM B649 / ASME SB649 DIN 17440 EN10088-3 EN10272 NACE MR01-75 / ISO 15156 SEW 400-VdTÜV421 |
BRANDS | URANUS B6™ VLX904™ AL-904L™ CRONIFER 1925™ 2RK65™ |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2 max | 1 max | 0.040 max | 0.030 max | 19.0-23.0 | 4.0-5.0 max | 23.00 – 28.00 | 1.0-2.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Cut to size on request (tolerance +2/-0 mm). Standard lengths of 904L Stainless Steel Bars 2000 mm up to 6000 mm available
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 904L.0 |
Yes, Stainless Steel 904L Round Bars/Rod can be easily welded, machined, and fabricated, offering excellent work ability due to its high nickel and chromium content, ensuring durability and resistance to corrosion.
Yes, Stainless Steel 904L Round Bars/Rod can be used at high temperatures, typically up to 1000°F (537°C), maintaining excellent corrosion resistance and strength in elevated thermal environments.
Yes, Stainless Steel 904L Round Bars/Rod can be fully recycled without losing quality. Stainless steel is highly recyclable, making it an eco-friendly material for various applications.
SS 904L round bars/rods are employed in shafts, marine propeller parts, chemical processing equipment, piping and flanges, and structural components of oceanic or coastal installations. Also employed in heat exchangers, saltwater equipment, and conditions where acid or chloride attack is common. In the pharmaceutical, food, and beverage industry for hygiene, corrosion resistance, and cleanliness. Also utilized in architectural columns or exposed round details in coastal or contaminated environments where rust resistance and strength are needed. The round shape is perfect for rotational components, fasteners, and parts requiring smooth finishes and balanced stress profiles.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
